View a Larger Image of TurboCone Dust Collector, 3HP 1PH 230V, 2-Micron Canister Kit, Model PM1900TX-CK1
  • View a Different Image of TurboCone Dust Collector, 3HP 1PH 230V, 2-Micron Canister Kit, Model PM1900TX-CK1
  • Default
Item 849661
Model 1792072K

Powermatic - TurboCone Dust Collector, 3HP 1PH 230V, 2-Micron Canister Kit, Model PM1900TX-CK1



  • Ships for Free
  • - Contiguous 48 States Shipping Only

    Learn More
  • - Ships from Manufacturer, Expedited Shipping Unavailable

    Learn More
  • - Not Available for Express and Overnight Shipping.

    Learn More
  • - Ships in 5 Business Days.

Save 15% On Jet and Powermatic Now Through May 31, 2020

Compare With


Performance: Only fine particles move to the filter chamber making manual cleaning easier and decreasing health concerns

Prevention: Prevents the central airflow from floating chips into the filter chamber decreasing rapid performance drop due to premature clogging

Efficiency: Chips are better contained for increased packing density requiring fewer collection bag changes

TurboCone improves chip separation and collector bag packing efficiency
The cone eliminates premature filter clogging for sustained performance
Remote-controlled digital timer can be programmed for up to 99 minutes
All-metal duct construction for rigidity and improved air flow
2-micron canister filters offer over six times filtering surface area of standard bags
The large impeller is powered by a 3HP motor for peak performance
Triple 4” dust ports allow for several hoses to be attached at the same time
Collection bags use a snap ring for rapid installation/removal
10 cubic feet collection bag capacity reduces number of bag changes.
Tall filter bags require less cleaning due to the larger surface area
Four swivel casters for shop maneuverability

Length : 46 inch
Model Number: 1792072K
Overall Dimensions: 61" x 30" x 72"
Height: 45"
Width: 23"
Length: 46"
Net Weight: 268 lbs
Remote Control: Yes
Sound Rating: 75-90 dB
1-Hose Connection Diameter: 8"
2-Hoses Connection Diameter: 4"
3-Hoses Connection Diameter: 4"
Bag Diameter: 20"
Filter Bag/Canister Length: 26"
Collection Bag Capacity: 10 cubic foot
Collection Bag Length: 30"
Air Flow @ 4": 236 cu.ft/min
Air Flow @ 8": 1,782 cu.ft/min
Static Pressure: 11.31 inch of water
Particle Size (Micron): 98% of 2 micron
particles 86% of 1 micron particles
Velocity @ 4": 5,200 foot per minute
Air Inlet: (1) at 8" or (3) at 4"
Impeller Diameter: 14"
Impeller Fins: 7
Impeller Material: Steel
Separator Tank Diameter: 20"
Separator Tank Height: 10"
Motor Power: 3 HP
Motor Phase: 1 Ph
Motor Voltage: 230V
Prewired Voltage: 230V
Motor Current: 15A
