• The helical cutterhead provides smoother, quieter cutting and finer finish than conventional systems
• Powerful 3HP TEFC motor controlled with a magnetic switch for safety
• Three V-belts transfer maximum power to the cutterhead
• Serrated steel infeed roller and smooth steel outfeed roller allow for 1/8" maximum depth of cut and trouble free operation
• Large cast iron handwheel positions table quickly and easily
• Large, precision ground cast iron table and extensions provide maximum workpiece support
• Two speed gearbox features automatic chain tensioner
• One-piece welded steel stand has built-in lockable casters
• Steel top-mounted return rollers speed repetitive cuts
• Angled dust chute with 4" port positions collection hose away from the work area while providing efficient chip and dust collection
• Table locks firmly in place, preventing movement during cutting

• 3HP TEFC motor with magnetic controls
• 4" diameter dust port
• Cast iron extension tables
• Closed stand with built-in casters
• Amps : 15
• Column Diameter (in) : 2-3/16
• Dust Collection Minimum CFM Required : 800
• Dust Port Diameter (OD/in) : 4
• Feed Rate (FPM) : 16 and 20
• Height (in): 43.5
• Infeed Roller Diameter (in) : 2.070
• Length (in): 48
• Maximum Depth of Cut (in): 1/4
• Maximum Full Width Depth of Cut (in): 1/8
• Maximum Planing Thickness (in): 6
• Maximum Planing Width (in): 14-7/8
• Minimum Planing Length (in) : 8
• Motor HP : 3HP
• Motor Phase : 1PH
• Motor Voltage : 230V
• Net Weight : 502 pound
• Outfeed Roller Diameter (in) : 2.070
• Overall Dimensions : 48 x 28 x 43-1/2
• Part Number : 1791213
• Readout Scale : inch/metric
• Rotation (Forward/Reverse) : Fwd
• Segmented Infeed Roller Diameter (in) : 2.070
• Table Size (in) : 15 x 48 (w/ extensions)
• Table Support : 4 column
• Tool Supplied : yes
• Width (in): 28
• Shipping weight 537 lb.
