California Air Tools

60065C 60 Gallon Air Compressor- 6.5 HP - 3 PH

Item #196055 Model CAT-60065C
$ 2,075 00
$ 2,075 00 Was $2,075.00
New
  • 60065C 60 Gallon Air Compressor- 6.5 HP - 3 PH
  • 60065C 60 Gallon Air Compressor- 6.5 HP - 3 PH
  • 60065C 60 Gallon Air Compressor- 6.5 HP - 3 PH
  • 60065C 60 Gallon Air Compressor- 6.5 HP - 3 PH
  • 60065C 60 Gallon Air Compressor- 6.5 HP - 3 PH
  • 60065C 60 Gallon Air Compressor- 6.5 HP - 3 PH
  • 60065C 60 Gallon Air Compressor- 6.5 HP - 3 PH
1 7

California Air Tools

60065C 60 Gallon Air Compressor- 6.5 HP - 3 PH

Item #196055 Model CAT-60065C
$ 2,075 00
$ 2,075 00 Was $2,075.00
California Air Tools 60065C Ultra Quiet & Oil-Free Air Compressor is designed to be one of the quietest 6. 5 Hp air compressors in the industry having only 85 decibels of sound. . . View More Details
Ships from Manufacturer Shipping Info

Purchase Note: This machine requires 3-phase power. Most residential power is single or 1-phase. Verify your power requirements before ordering.

Details

California Air Tools 60065C Ultra Quiet & Oil-Free Air Compressor is designed to be one of the quietest 6.5 Hp air compressors in the industry having only 85 decibels of sound compared to competitive models.

The Powerful 6.5 Hp 208-230 Volt / 60 Hertz / 3-Phase (range 200VAC to 240VAC) volt motor-pump operates at 3400 RPM creating up to 20 CFM air flow and is designed to increase duty cycle and allow for longer continuous run operations.

The Oil-Free Quad Piston Pump System is engineered for high performance and durability.

The large 60 Gallon ASME Steel Air Tank is just the right size to support a large facility including commercial business, manufacturing operations, autobody shops and other general pneumatics that require air volumes of up to 20 cfm.

Designed for the person looking for Power, Oil-Free Air Flow and at Least 30% Less Noise!

Features:
  • Ultra Quiet- 85 dB
  • Oil-Free Pump- Cleaner air for better tool operation
  • Less Maintenance and Costs
  • One Tank Pressure Gauge
  • 1/2" NPT Female Port
  • No Output Pressure Regulator- quick connector or air hose included
  • Condor Pressure Switch
  • Thermal Overload Protector
  • 120 PSI Maximum Pressure
  • 208-230 Volt / 60 Hertz / 3-Phase (acceptable voltage range 200VAC to 250VAC)
  • Amp Draw- 15A
  • 20 Amp Breaker Suggested
  • Time to Fill Tank From Empty to Full- 191 Seconds
  • Recovery Time From 92 PSI to 120 PSI- 35 Seconds
  • Less Heat that Dissipates More Efficiently
  • 60 Gallon ASME Steel 155 PSI Air Tank
  • Manual Drain Valve with Strainer Cleanout
  • Comes Complete with (4) Air Filters
  • Plug Type: Nema L15-20P (connect to L15-20R receptacle)
  • Cord Length: 7’
  • 70/30 Duty Cycle Rating
  • Commercial Use: Refer to State & City Codes
  • 1 Year Limited Warranty
  • Assembled in Mexico & USA with Global Components
Specifications:
  • 32.5" x 28" x 60.5"
  • 260 lbs
What's Included:
  • Manual
