Amana Tool

46460-K Spiral Plunge Corner Radius Up-Cut Router Bit 1/16"R 1/4"D 3/4"CH 1/4"SH 2-1/2"OL

Item #180656 Model 46460-K
Regular price $39.30
Sale price $39.30 Regular price $39.30
Skip to product information
1 of 1

Amana Tool

46460-K Spiral Plunge Corner Radius Up-Cut Router Bit 1/16"R 1/4"D 3/4"CH 1/4"SH 2-1/2"OL

Item #180656 Model 46460-K
Regular price $39.30
Sale price $39.30 Regular price $39.30
The Amana Spiral Plunge Corner Radius Up-Cut Router Bit is perfect for carving, lettering, decorative doors and sign manufacturing. Leaves an excellent finish and expels chips quickly. View More Details

Ships from Manufacturer

Shipping Info

Items you may need

  • 2-piece Plastic Cutting Bit Set for Axiom CNC Machine by Amana Tool

    Regular price $69.00
    Sale price $69.00 Regular price $69.00
    2-piece Plastic Cutting Bit Set for Axiom CNC Machine by Amana Tool alt 0
  • 46170-K 1/4" CNC Solid Carbide Compression Spiral Router Bit, 1/4 Diameter x 7/8 x 1/4 Inch Shank

    Regular price $77.99
    Sale price $77.99 Regular price $77.99
    46170-K 1/4" CNC Solid Carbide Compression Spiral Router Bit, 1/4 Diameter x 7/8 x 1/4 Inch Shank alt 0
  • 45771-K 30° Solid Carbide Engraving / Carving Router Bit, 0.005 Tip Width x 1/4 Inch Shank

    Regular price $46.99
    Sale price $46.99 Regular price $46.99
    45771-K 30° Solid Carbide Engraving / Carving Router Bit, 0.005 Tip Width x 1/4 Inch Shank alt 0
  • CNC Sign Making Router Bit Set - 1/4" SH

    Regular price From $125.99
    Sale price From $125.99 Regular price $125.99
    CNC 3-PC Signmaking Set alt 0
  • RC-1148 Insert V-Groove 60 Deg x 59 / 64 x 1/4 Inch Shank CNC Router Bit

    Regular price $92.30
    Sale price $92.30 Regular price $92.30
    RC-1148  Insert V-Groove 60 Deg x 59 / 64 x 1/4 Inch Shank CNC Router Bit alt 0

Details

The Amana Spiral Plunge Corner Radius Up-Cut Router Bit is perfect for carving, lettering, decorative doors and sign manufacturing. Leaves an excellent finish and expels chips quickly.


Excellent for Cutting:


  • MDF
  • Soft/Hard Plastic
  • Soft/Hard Wood

Amana Spektra bits feature a nACo nanocomposite coating with an extreme nano hardness and heat resistance. With a brilliant distinctively-tinted coloring nACo provides additional improvements in four critical aspects of router tooling:


  • nACo coating is a micro-thin ceramic coating which enables the tool's cutting edge to retain crucial sharpness and lubricity. This provides longevity and produces cutting results of the highest quality.
  • Coating prevents high heat and oxidation which is detrimental to cutting tool performance.
  • Multi-colored hues, while attractive, will dissipate upon use and yet coating will remain fully effective.
  • nACo offers approximately 4,500 Vickers for impressive solid hardness on cutting areas of the tool, for an increase up to 2.5 times compared to uncoated bits.

Note: Blue based color dissipates immediately upon use. nACo nanocomposite coating will not wear off.


Specifications

  • Diameter: 1/4"
  • Radius: 1/16"
  • Cutting Height: 3/4"
  • Shank: 1/4"
  • Overall Length: 2-1/2"










https://www.woodcraft.com/media/W1siZiIsIjIwMTkvMDUvMDEvMTAvNTQvMTAvNTE1L3ZlY3RyaWNfd2ViX2xvZ29fc21hbGxlci5qcGciXV0/vectric-web-logo-smaller.jpg?sha=fb58496759ac82e1


Download Vectric 46460-K File



Tool #46460-K Vectric Compatible Tool File

46460-K tool file to be used with all versions of Vectric software from version 8.0 and up. Works with Aspire, VCarve, Cut2D, Cut3D and PhotoVCarve.


This tool file is to be used as a starting point for your CNC projects and the parameters should be adjusted based on your project and material.


Installation:

1. Download to a safe location such as your desktop.

2. In the software, open the Tool Database and use the import option to load the file from the safe location.


Vectric File Warning

The Vectric .tool file should only be used in conjunction with the Amana Tool item number specified. Using this file with other brands is dangerous to the operator and CNC machine.
