SuperMax

19-38 Drum Sander

Item #857815 Model SUPMX-71938-D
Regular price $1,799.10
Sale price $1,799.10 Regular price $1,999.00

This item has an additional shipping charge

Save 10% on Laguna Machines & Accessories!

Skip to product information
Sale
1 of 8

SuperMax

19-38 Drum Sander

Item #857815 Model SUPMX-71938-D
Regular price $1,799.10
Sale price $1,799.10 Regular price $1,999.00

This item has an additional shipping charge

Save 10% on Laguna Machines & Accessories!

Take your sanding to the next level with a SuperMax sander. They have addressed issues common with other drum sanders on the market to create one of t. . . View More Details

Enjoy Extended Coverage with a Woodcraft Protection Plan

Ships from Manufacturer

Shipping Info

Items you may need

  • Wixey Digital Read Out for SuperMax Sanders

    Regular price $89.10
    Sale price $89.10 Regular price $99.00
    Wixey Digital Read Out for SuperMax Sanders alt 0
  • Pre-Cut Sandpaper Wrap for 19-38 Drum Sander

    Regular price From $15.75
    Sale price From $15.75 Regular price $17.50
    Individual Sandpaper Wrap for 19-38 Sander, 36 Grit alt 0

Details

Take your sanding to the next level with a SuperMax sander. They have addressed issues common with other drum sanders on the market to create one of the best you can find. The 19-38 Drum Sander comes standard on SuperMax’s open stand, and the drum is pre-wrapped with 80 grit sandpaper. It features simple alignment: just one nut will adjust the conveyor to parallel the sanding head making aligning the conveyor to the sanding head quickly and easily as well as indexed alignment settings. The 19-38 has an indexed alignment setting for narrow and wide stock. When sanding stock wider than 19”, the index level will properly adjust the conveyor for flawless wide sanding. There are easy height adjustments: a thrust bearing below the handle and a nut positioned above prevents the drum from moving out of the set position while sanding and there’s no backlash or slop in the height adjustment mechanism allowing for easier and smoother height adjustments. It also features an extra-wide conveyer which properly supports stock over 19” wide. The conveyor table is 22” wide to add support to the workpiece.
Additionally, the SuperMax 19-38 drum sander features INTELLISAND Technology which automatically adjusts conveyor speed based on load and prevents gouging, damaging, or burning stock. INTELLISAND also provides a consistent finish even with varying grain patterns and densities. These drum sanders also have a Flatness Guarantee: the precision-flattened steel conveyor bed is reinforced with four steel cross sections for no “flex”; guaranteeing flatness to less than .010” across the width of the sander. Its patented Abrasive Attachment System effectively tensions the abrasive wraps preventing abrasive end overlap, and the 19-38 has easy access to abrasive fastening unlike other drum sanders along with an extra wide space to access fasteners to eliminate the need for special tools. The self-cooling drum prevents overheating and extends the life of the abrasive. Its tension rollers are adjustable in height and hold down pressure eliminating snipe. This unit also has excellent dust extraction as the dust cover is formed to the shape of the drum. It is metal, not plastic, and is formed to maximize air flow. The unit is constructed of heavy-duty cast iron for strength, rigidity, and reduced vibration.
Specifications:
  • Drive Motor (TEFC): 1-3/4 HP
  • Power Requirements: 110V 20 Amp
  • Conveyor Motor: 43 in/lb. torque, direct drive DC motor, infinitely variable 0-10 FPM
  • Maximum Width: 38” (two passes)
  • Minimum Length: 2-1/4”
  • Maximum Thickness: 4”
  • Minimum Thickness: 1/32”
  • Dimensions: 27” L x 46” W x 52” H
  • Drum: 5” x 19” extruded aluminum
  • Drum Speed: 1740 RPM
  • Dust Hood: One 4” vacuum port (minimum 600 CFM recommended)
  • Shipping Weight: 286 lbs. (3 boxes including stand).

Shipping / Billing Information

This product ships direct from the manufacturer:

  • Your order will ship in approximately 7-14 business days.
  • This product is considered special order. Your account will be charged when you place your order.
  • Express or overnight shipping is not available for this product.
  • Ships by Ground to the 48 contiguous states. Cannot ship to Alaska, Hawaii, PO Boxes, APOs, US Territories, Canada or other foreign countries.
  • Liftgate and Residential Delivery is covered with the excess weight fee, and the freight company will call the day before delivery to set up a time at no charge to you.

Return Information

Laguna does not accept returns. If your shipment was damaged, please refuse delivery, for defective items, please contact Woodcraft Supply customer service @ 1-800-535-4482.

If purchased at a Woodcraft Store, please return the item directly to the store where your purchase was made.

Warranty Information

New woodworking machines sold by Laguna Tools carry a two-year warranty effective from the date of shipping. Laguna bandsaw blades' welds are backed by their 1-yr manufacturer's warranty. Machines sold through dealers must be registered with Laguna Tools within 30 days of purchase to be covered by this warranty. Laguna Tools guarantees all new machine sold to be free of manufacturers’ defective workmanship, parts and materials. Laguna Tools will repair or replace, without charge, any parts determined by Laguna Tools, Inc. to be a manufacturer’s defect. They require that the defective item/part be returned to Laguna Tools with the complaint. In the event the item/part is determined to be damaged due to lack of maintenance, cleaning or misuse/abuse, the customer will be responsible for the cost to replace the item/part, plus all related shipping charges.

For warranty repair information, call 1-800-332-4094.
