• Motor Power (HP) : 1-3/4

• Motor Current (Amps) : 15/7.5
• Motor Phase : 1
• Motor Voltage (V.) : 115/230
• Prewired Voltage (V.) : 115
• Recommended Circuit Size (Amps.) : 20A (for 115V)
• Table Height from Floor (In.) : 34-1/4
• Table Size (In.) : 20 x 27
• Table Type : Cast Iron
• Total Work Surface (In.) : 75-3/8 x 27
• A blade surround and collection hose provide an unobstructed path, maximizing dust collection
• Conveniently located hands free power switch
• Tool-less guard assembly with independent side leaves is easy to use, maximizing safety
• The sturdy miter gauge pivots 60 degrees to either side, allowing easy adjustment for a full range of cuts
• Exclusive AccuFence provides rigidity and precision
• The poly-V belt drive system reduces vibration and maximizes efficiency
• Ergonomically designed 7” handwheels provide momentum – making blade height and bevel adjustments easy
• Arbor lock allows for one handed blade changes with minimal tools
• Cast iron work surface features a beveled edge
• Bevel scale is conveniently located with large, easy to read numbers
• Hinged motor cover provides quick access to the interior of the cabinet
• Arbor Diameter (In.) : 5/8
• Arbor Speed (RPM) : 4200
• Blade Diameter (In.) : 10
• Cast Iron Work Surface (In.) : 40 x 27
• Dust Collection Minimum CFM Required (CFM) : 350
• Dust Port Outside Diameter (In.) : 4
• Maximum Depth of Cut (In.) : 3-1/8
• Maximum Depth of Cut at 45 Degrees (In.) : 2-1/8
• Maximum Diameter of Dado (In.) : 8
• Maximum Rip Left of Blade (In.) : 12
• Maximum Rip Right of Blade (In.) : 52
• Maximum Width of Dado (In.) : 13/16
• Weight (Lbs.) : 393.8
