The Maksiwa RBB.4G Edge Trimmer streamlines edge banding cleanup by combining edge trimming, end trimming, scraping and polishing in one machine. Designed to work alongside compatible edgebanders, it delivers a consistent finished edge on material up to 1 mm thick and panels up to 70 mm high while reducing manual handling between operations.
An automatic feed system moves panels through all four finishing stations at a steady 56 feet per minute, helping maintain uniform results from piece to piece. Height adjustment allows quick setup for different panel sizes, while the included router and bit put the machine to work immediately. The two-sided scraper removes imperfections left after edge application, and the polishing station leaves a clean, professional appearance ready for assembly or installation.
A built-in 4" dust port supports workshop dust collection, helping keep chips and debris under control during production. When paired with Maksiwa CBC.MR or CBC/2.MR edgebanders, the RBB.4G creates an efficient edge banding workflow with fewer secondary finishing steps.
Features:
- Four finishing groups: edge trim, end trim, scrape and polish
- Processes edge banding up to 1 mm thick
- Handles panels up to 70 mm high
- Automatic panel feed system
- Adjustable height settings
- Built-in 4" dust collection port
- Includes router and router bit
- Compatible with CBC.MR and CBC/2.MR edgebanders
Specifications:
- Voltage: 110V
- Amperage: 6A
- Power Output: 2100W
- Frequency: 60Hz
- Feed Type: Automatic
- Feed Speed: 56 ft/min
- Maximum Panel Height: 2-3/4"/70mm
- Workpiece Length Range: 6"/160mm to 138"/3500mm
- Minimum Workpiece Width: 3"/75mm
- Edge Band Thickness Range: 0.4mm-1mm
- Scraper Type: 2-Sided Straight
- Router Bit Type: 2-Flute Straight
- Dust Collection Port Size: 4"
- Machine Dimensions: 51-3/16" x 27-1/2" x 25"
- Weight: 159 lb
- Warranty: 2 Years
