- 5 HP main motor maintains blade speed through heavy cuts
- 3/4 HP scoring motor reduces tear-out on panel edges
- Sliding table provides smooth, controlled material movement
- Telescoping crosscut fence extends to 134"
- Rip fence with micro adjustment supports precise positioning
- Swing-away overhead guard allows quick access to blade area
- Central dust port routes chips away from cutting path
- Soft start reduces startup load on motor
Specifications:
- Main Motor Power: 5 HP
- Scoring Motor Power: 3/4 HP
- Voltage: 220 V
- Phase: 1PH
- Blade Capacity: 12"/14"
- Maximum Blade Diameter: 14"
- Minimum Blade Height: 1"/25 mm
- Maximum Scoring Blade Diameter: 4-3/4"/120 mm
- Arbor Size: 30 mm (Main)/20 mm (Scoring)
- Maximum Cutting Height At 90° (14" Blade): 4-1/2"/155 mm
- Maximum Cutting Height At 90° (12" Blade): 3-1/2"/90 mm
- Maximum Cutting Height At 45° (14" Blade): 2-3/4"/70 mm
- Maximum Cutting Height At 45° (12" Blade): 2-3/8"/62 mm
- Main Blade Speed: 4000 RPM
- Scoring Blade Speed: 8000 RPM
- Dust Port Size: 4"/100 mm
- Sliding Table Length: 63"
- Sliding Table Width: 12"
- Main Table Size: 21-1/2" x 35-1/4"
- Rip Capacity: 51"
- Crosscut Capacity: 134"
- Shipping Dimensions: 83" x 46" x 46"
- Weight: 1405/1525 lb
What's Included:
- (1) Panelsaw Machine
- (1) Blade System
- (1) Scoring Blade System
- (1) Sliding Table
- (1) Crosscut Fence System
- (1) Rip Fence System
- (1) Hold-Down Clamp
- (1) Rip Shoe
- (1) Push Handle
- (1) Table Extension
- (1) Control Panel
- (1) Dust Port
- (1) Overhead Guard System
Shipping / Billing Information
This product ships direct from the manufacturer:
- Your order will ship in approximately 4 weeks.
- This product is considered special order. Your account will be charged when you place your order.
- Express or overnight shipping is not available for this product.
- Ships by Ground to the 48 contiguous states. Cannot ship to Alaska, Hawaii, PO Boxes, APOs, US Territories, Canada or other foreign countries.
- Liftgate and Residential Delivery is covered with the excess weight fee, and the freight company will call the day before delivery to set up a time.
Return Information
Warranty Information
New woodworking machines sold by Laguna Tools carry a two-year warranty effective from the date of shipping. Laguna bandsaw blades' welds are backed by their 1-yr manufacturer's warranty. Machines sold through dealers must be registered with Laguna Tools within 30 days of purchase to be covered by this warranty. Laguna Tools guarantees all new machine sold to be free of manufacturers’ defective workmanship, parts and materials. Laguna Tools will repair or replace, without charge, any parts determined by Laguna Tools, Inc. to be a manufacturer’s defect. They require that the defective item/part be returned to Laguna Tools with the complaint. In the event the item/part is determined to be damaged due to lack of maintenance, cleaning or misuse/abuse, the customer will be responsible for the cost to replace the item/part, plus all related shipping charges.
For warranty repair information, call 1-800-332-4094.
