Features:
- Single head configuration with drum and platen combination
- Pneumatic belt oscillation distributes belt wear
- Two conveyor feed speeds for material control
- Cast iron bed supported by four Acme threaded screws
- Electric bed height adjustment with manual micro adjustment
- Fully adjustable platen with felt and graphite surface
- Rubber drum for stock removal
- Front safety bar stops belt operation
- Air disc brake on main motor
Specifications:
- Model Number: MSANWB25X60-1K-7.5-0197
- Motor Power: 7.5 HP
- Voltage: 220 V
- Phase: Single Phase
- Frequency: 60 Hz
- Motor Speed: 1750 RPM
- Conveyor Motor Power: 1 HP
- Conveyor Speed: 22/49 FPM
- Max Capacity Height: 5.9" (150 mm)
- Max Width Capacity: 24-3/8"
- Belt Size: 25" x 60"
- Drum Size: 4" x 26"
- Configuration: Roller/Platen Combo
- Bed Height Range: 32"–38"
- Air Pressure Requirement: 75 PSI
- Dust Port Size: 5" x 3
- Footprint Size: 20" x 40"
- Overall Size: 40" x 50"
- Machine Height: 66-1/4"
- Certification: CSA Approved
- Net Weight: 1650 lb
- Gross Weight: 1920 lb
What's Included:
- (1) Widebelt Sander
- (1) Rubber Drum Assembly
- (1) Platen Assembly
Shipping / Billing Information
This product ships direct from the manufacturer:
- Your order will ship in approximately 4 weeks.
- This product is considered special order. Your account will be charged when you place your order.
- Express or overnight shipping is not available for this product.
- Ships by Ground to the 48 contiguous states. Cannot ship to Alaska, Hawaii, PO Boxes, APOs, US Territories, Canada or other foreign countries.
- Liftgate and Residential Delivery is covered with the excess weight fee, and the freight company will call the day before delivery to set up a time.
Return Information
Warranty Information
New woodworking machines sold by Laguna Tools carry a two-year warranty effective from the date of shipping. Laguna bandsaw blades' welds are backed by their 1-yr manufacturer's warranty. Machines sold through dealers must be registered with Laguna Tools within 30 days of purchase to be covered by this warranty. Laguna Tools guarantees all new machine sold to be free of manufacturers’ defective workmanship, parts and materials. Laguna Tools will repair or replace, without charge, any parts determined by Laguna Tools, Inc. to be a manufacturer’s defect. They require that the defective item/part be returned to Laguna Tools with the complaint. In the event the item/part is determined to be damaged due to lack of maintenance, cleaning or misuse/abuse, the customer will be responsible for the cost to replace the item/part, plus all related shipping charges.
For warranty repair information, call 1-800-332-4094.
