Features:
- 15 HP three-phase cutterhead motor maintains cutting speed under full-width load
- Electronic variable feed speed adjusts from 10–30 FPM
- PLC height control positions the bed automatically to set thickness
- Digital readout supports accurate thickness adjustments
- ShearTec II cutterhead with 174 carbide inserts reduces tear-out
- Segmented infeed roller maintains consistent pressure across uneven stock
- Dual outfeed rollers support smooth material exit
- Retractable table rollers assist with stock movement
- Cast table extensions increase support on longer boards
- 5″ dust port supports chip extraction
Specifications:
- Maximum Stock Width: 25″
- Maximum Stock Thickness: 9″
- Minimum Stock Thickness: 1/8″
- Maximum Stock Removal (1–12″ Width): 6 mm/1/4″
- Maximum Stock Removal (12–25″ Width): 3 mm/1/8″
- Feed Speed Range: 10–30 FPM
- Table Size: 52″ x 26″
- Extension Size: 10″ x 26″
- Cutterhead Type: Spiral Insert
- Cutterhead Diameter: 3-1/2″
- Cutterhead Speed: 4800 RPM
- Insert Count: 174
- Insert Type: Carbide, 4-Sided
- Motor Power (Cutterhead): 15 HP
- Motor Power (Feed): 3/4 HP
- Motor Power (Vertical): 3/4 HP
- Voltage: 220 V
- Current: 37 A
- Dust Port Size: 5″
- Machine Weight: 1500 lb
- Shipping Dimensions: 35″ x 53″ x 60″
What's Included:
- (1) Industrial Planer
- (1) ShearTec II Spiral Cutterhead (Installed)
- (174) Carbide Inserts
- (1) Infeed Roller Assembly
- (2) Outfeed Rollers
- (1) Segmented Pressure Bar
- (1) Planer Table
- (2) Table Extensions
- (1) Dust Port (5")
- (1) PLC Control Unit
- (1) Digital Readout
- (1) Manual Height Adjustment System
- (1) Control Panel
Shipping / Billing Information
This product ships direct from the manufacturer:
- Your order will ship in approximately 4 weeks.
- This product is considered special order. Your account will be charged when you place your order.
- Express or overnight shipping is not available for this product.
- Ships by Ground to the 48 contiguous states. Cannot ship to Alaska, Hawaii, PO Boxes, APOs, US Territories, Canada or other foreign countries.
- Liftgate and Residential Delivery is covered with the excess weight fee, and the freight company will call the day before delivery to set up a time.
Return Information
Warranty Information
New woodworking machines sold by Laguna Tools carry a two-year warranty effective from the date of shipping. Laguna bandsaw blades' welds are backed by their 1-yr manufacturer's warranty. Machines sold through dealers must be registered with Laguna Tools within 30 days of purchase to be covered by this warranty. Laguna Tools guarantees all new machine sold to be free of manufacturers’ defective workmanship, parts and materials. Laguna Tools will repair or replace, without charge, any parts determined by Laguna Tools, Inc. to be a manufacturer’s defect. They require that the defective item/part be returned to Laguna Tools with the complaint. In the event the item/part is determined to be damaged due to lack of maintenance, cleaning or misuse/abuse, the customer will be responsible for the cost to replace the item/part, plus all related shipping charges.
For warranty repair information, call 1-800-332-4094.
