Jet
10" Benchtop Drum Sander - 1 HP 1 Ph 115V - JWDS-1020
Item #169616
Model JT9-723510
Regular price
$1,099.99
Sale price
$1,099.99
Regular price
$1,099.99
Unit price
per
Jet
10" Benchtop Drum Sander - 1 HP 1 Ph 115V - JWDS-1020
Item #169616
Model JT9-723510
Regular price
$1,099.99
Sale price
$1,099.99
Regular price
$1,099.99
Unit price
per
The Jet® Benchtop 10" Drum Sander model JWDS-1020 sander packs a powerful 1HP motor that will sand boards up to 3" thick and 20" wi. . .
View More Details
Details
The Jet® Benchtop 10" Drum Sander model JWDS-1020 sander packs a powerful 1HP motor that will sand boards up to 3" thick and 20" wide. The innovative patented dust hood ensures dust is funneled to the 4" dust port that easily connects to a Dust Collector. Adjusting the table back to parallel is convenient with just the turn of a dial. The self-cooling extruded aluminum sanding drum protects the sanding surface from heat damage, preventing waste.
Features:
- Parallelism adjust dial features a stop to quickly return the conveyor bed to a flat position
- Infinitely variable-speed control allows the user to choose the optimal feed rate
- Open ended design allows for up to 20" of sanding capacity with 2 passes
- Extruded aluminum drum is designed to dissipate heat and protect wood from heat-damage
- Redesigned conveyor system pulls the work piece through the sander instead of pushing
- Toolless abrasive take-up fasteners make changing abrasives quick and easy
- Precision-flattened reinforced steel conveyor bed supports the boards passing under the sanding drum
- Control system with integrated circuit breaker protects motor from over heating
Specifications:
- Motor: 1HP, 1Ph, 8A, 115V/60Hz
- Drum speed (rpm): 1720
- Dust port: 4”
- Drum length: 10"
- Drum diameter: 5”
- Conveyor speed: 0-10 FPM
- Conveyor table size: 10" x 15"
- Abrasive installed: 80 Grit - 3" wide, Aluminum Oxide
- Maximum board thickness: 3”
- Minimum board thickness: 1/32”
- Minimum board length: 2-3/8”
- Maximum board width: 10" with one pass
- Maximum board width: 20” with 2 passes
- Style: Benchtop
- Net weight: 73 lb - machine only
What's Included:
- (1) Jet® Benchtop 10" Drum Sander - 1 HP 1 Ph 115V - JWDS-1020
