• Hydraulic controlled down feed with adjustable manual return
• Automatic shut off at the end of the cut
• Dual operating modes with head descent control lock switch. Pre-set the down feed and shut switch so down feed does not need resetting after each cut
• Powerful, flame tempered, manual clamping vise. Hand wheel adjusted with quick release lever for rapid vise opening and closing action. The vise clamps material firmly
• Traversing vise can be used left or right of the blade
• Ergonomic designed for operator’s comfort and control
• Gearbox is direct bolted to the bow for less vibration, and positive drive gear box is direct driven via steel and bronze gears, no belts and pulleys to contend with
• CE Certified electronics. Low voltage switches. Thermo over load protection, low voltage protection with low voltage trigger motor start switch and blade cover interlock
• Blade tensioning is done via. A hand wheel and color-coded gauge tensioning system taking the guesswork out of tensioning
• Miters up to 60° right / 45° left. Mitering pre-sets with flip up and pin stops makes set up fast and has precise with miter scale for all angles in between. The head turns-the material doesn’t
• Horizontally mounted guide arms for more rigidity and straightest cuts. Guides are rollers with carbide inserts that are fully adjustable and replaceable
• Electric coolant pump and self-contained coolant system
• Steel fabricated base, and stock stop gauge

• Capacity: 10" Round
• Horsepower: 2.75
• Voltage: 220V 3 phase
• Maximum Blade Speed: 230 FPM
• Blade Width: 1"
• Blade Length: 108"
• Blade Speed: 115-230 FPM
• Solid Round 90˚ Capacity: 10"
• Solid Round 45˚ Right Capacity: 8"
• Solid Round 60˚ Right Capacity: 5"
• Solid Square 90˚ Capacity: 7 1/2"
• Solid Square 45˚ Right Capacity: 7 1/2 / 6 3/4"
• Solid Square 60˚ Right Capacity: 5"
• Solid Rectangle 90˚ Capacity: 10 1/2" x 7 3/4"
• Solid Rectangle 45˚ Right Capacity: 8 1/4" x 3 1/8"
• Solid Rectangle 60˚ Right Capacity: 4 3/4" x 5 1/4"
• Worktable Height: 37"
• Height: 74"
• Floor Space: 28" x 66"
• Floor Space Left to Right: 28" x 66"
• Floor Space Front to Back: 28" x 66"

• Steel base
• 1 standard bi-metal blade
• Traversing, manual vise
• Coolant
• Stock stop gauge

New woodworking machines sold by Laguna Tools carry a two-year warranty effective from the date of shipping. Laguna bandsaw blades' welds are backed by their 1-yr manufacturer's warranty. Machines sold through dealers must be registered with Laguna Tools within 30 days of purchase to be covered by this warranty. Laguna Tools guarantees all new machine sold to be free of manufacturers’ defective workmanship, parts and materials. Laguna Tools will repair or replace, without charge, any parts determined by Laguna Tools, Inc. to be a manufacturer’s defect. They require that the defective item/part be returned to Laguna Tools with the complaint. In the event the item/part is determined to be damaged due to lack of maintenance, cleaning or misuse/abuse, the customer will be responsible for the cost to replace the item/part, plus all related shipping charges.

For warranty repair information, call 1-800-332-4094.
