Features:
- Heavy steel channel frame and table
- Long 8” stroke
- Self-contained fast, efficient two speed hand operated pump conveniently located
- Traversing head L/R for off center pressing applications
- Removable nose piece to allow for custom nose piece installation
- Table can be adjusted for maximum or minimum vertical opening to accommodate a variety of work pieces and to minimize required ram travel
- Large diameter, single acting polished piston with internal spring return to eliminate external pinch points
- Comes complete with table plates, gauge, and owner’s manual
Specifications:
- Capacity: 20 tons
- Operation Manual
- Horsepower: n/a
- Voltage: n/a
- Width Between Uprights: 22"
- Width Between Table Channels: 4"
- Minimum Ram to Table: 4"
- Maximum Ram to Table: 39"
- Ram Travel: 8"
- Screw Travel: n/a
- Horizontal Workhead Travel: left/right of center
- Footprint: 34" x 26"
- Height: 70"
- Weight: 283 lbs
- Base: 34" x 26"
- Ram Advance Speed: 3/16" per stroke
- Pressing Speed: n/a
- RPM: n/a
- Air Pressure: n/a
What's Included:
- Frame
- Flat Ram Nose
- Combination Table Plates/V-Blocks
- Step Reduced Ram Nose
