• Fast, efficient single speed hand pump with adjustable mounting for maximum ergonomic operation
• Convenient top mounted gauge reads in tons and psi to monitor pressure
• Table can be adjusted for maximum or minimum vertical opening to accommodate a variety of work pieces and to minimize required ram travel
• Large diameter, single acting polished piston with internal spring return to eliminate external pinch points
• The hydraulic pressing cylinder can be relocated right or left of center for unusual work pieces

• Capacity: 10 tons
• Operation Manual
• Horsepower: n/a
• Voltage: n/a
• Width Between Uprights: 16-3/4"
• Width Between Table Channels: 3”
• Minimum Ram to Table: 4”
• Maximum Ram to Table: 16”
• Ram Travel: 6”
• Screw Travel: n/a
• Horizontal Workhead Travel: left/right of center
• Footprint: 23” x 18”
• Height: 36”
• Weight: 165 lbs
• Base: 23” x 18”
• Ram Advance Speed: 1/8" per stroke
• Pressing Speed: n/a
• RPM: n/a
• Air Pressure: n/a

• Frame
• Flat Ram Nose
• Combination Table Plates/V-Blocks
• Step Reduced Ram Nose

New woodworking machines sold by Laguna Tools carry a two-year warranty effective from the date of shipping. Laguna bandsaw blades' welds are backed by their 1-yr manufacturer's warranty. Machines sold through dealers must be registered with Laguna Tools within 30 days of purchase to be covered by this warranty. Laguna Tools guarantees all new machine sold to be free of manufacturers’ defective workmanship, parts and materials. Laguna Tools will repair or replace, without charge, any parts determined by Laguna Tools, Inc. to be a manufacturer’s defect. They require that the defective item/part be returned to Laguna Tools with the complaint. In the event the item/part is determined to be damaged due to lack of maintenance, cleaning or misuse/abuse, the customer will be responsible for the cost to replace the item/part, plus all related shipping charges.

For warranty repair information, call 1-800-332-4094.
