Get perfectly level, wobble-free cabinet shelves every time with the Milescraft CabinetMate Drill Template. Designed for accuracy, speed, and durability, this jig makes drilling shelf pin holes a simple, repeatable process—without the trial and error of homemade templates.
The precision-molded body features two rows of 11 holes spaced on 32mm centers for standard shelf pin layouts, offset 1-7/16" and 2-1/2" from the edge to suit a variety of cabinet designs. The included 1/4" brad-point ShelfPin Bit, guided by a spring-loaded collar, ensures every hole is perfectly centered and clean.
Built for convenience, the CabinetMate includes a storage compartment for your bit and indexing pins, plus the ability to mark Euro-style hinge locations—making it one of the most versatile cabinet jigs available.
Ideal for cabinetmakers, woodworkers, and DIYers who demand consistent, professional-quality results on every project.
Features:
- Drill precise, evenly spaced shelf pin holes with 32mm system accuracy
- Two 11-hole rows spaced 1-7/16" and 2-1/2" from the jig edge
- Includes 1/4" brad-point ShelfPin Bit with spring-loaded guide
- Allows marking for Euro-style hinge hole locations
- Rigid, long-lasting body won’t flex or wear like shop-made jigs
- Built-in storage for bit and indexing pins keeps everything organized
- Ideal for building or adjusting cabinet shelves and furniture
Specifications:
- Cutting Diameter: 0.25"
- Item Dimensions: 16.65" x 7.13" x 1.38"
- Minimum Bore Diameter: 0.25"
Whats Included:
- (1) CabinetMate Drilling Template With 1/4" Guided Drill Bit
